Automatic Stator Coil Winding Machine for Two Poles Stator
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- Dimension：2100*1250*1830mm
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
Base Info
- Model NO.：WIND-2-SW
- Transport Package：Wooden Case
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-2-SW Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Automatic Stator Coil Winding Machine For Two Poles Stator
This coil winding machine adpots a steel frame with two working stations. The winding speed can reach up to 450rpm in particular conditions of wire size. Travel and swing angle is adjusted within 150-220mm. It can be used as stand alone machine or integrated into a production line.(1)Specification
| Wire diameter | 0.25~0.8mm |
| Stator OD | 50~90mm |
| Stator ID | 30~50mm |
| Stack height | 20~45mmm |
| Pole No. | Two |
| Movement | Stepping/Auto |
| Voltage | AC380V,50/60Hz |
| Air pressure | 0.4~0.7MPa |
| Weight | 1800Kg |
| Dimension | 2100x1250x1830mm |
(2)Application
Suitable for two poles stators.
(3)FeaturesNo skilled operator requiredThis machine can be customized accordinglyRigid design frameFully automatic working cycle after loading of the statorQuick change-over of toolingPLC control, fault display
