Automatic Generator Motor Stator Coil Winding Inserting Machine

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：380V
  • Condition：New
  • Automation Type：High Autoamtic
  • Working Station：Three
  • Stator Diameter：0~150mm
  • Stator Stack Length：30~120mm

Base Info

  • Model NO.：Q3L1-75,130T
  • Power Supply：380V 50,60Hz
  • Air Source：0.6~0.8MPa
  • Weight：3500kg
  • Color：Ral9010 or as Per Customer Requirement
  • After-Sales Service：Overseas Service Center Available
  • Automatic：Automatic
  • Certification：CE
  • Transport Package：Ply-Wooden Case
  • Specification：customized
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479819000
  • Production Capacity：300PCS,Year

Description

Working station3Control methodtouch screenStator stack length30~120mmStator OD≤150mmStator ID50~120mmWire diameter0.18~1.2mmAir source0.6~0.8MpaVoltage380V 50/60HZPower11KWWeight3500KGDeminsion2550mm(L)X 2230mm(W)X2300mm(H)
Application:
It is suitable for air conditioner motor, washing machine motor, compression motor, fan motor, generator motor and pump motor.

Information needed for stator coil inserting machine inquiry
It will be better if customer could send us detailed drawing including below information.
1. Stator lamination drawing
2. Stator stack drawing
3. Stator winding drawing
4. Winding distribution drawing
5. Wedge and insulation paper drawing and its material
6. Stator application
7. Required productivity
8. Other technical requirement
If possible, it will be better if customer can send us samples

Automatic Generator Motor Stator Coil Winding Inserting Machine
Automatic Generator Motor Stator Coil Winding Inserting MachineAutomatic Generator Motor Stator Coil Winding Inserting MachineAutomatic Generator Motor Stator Coil Winding Inserting Machine
With good service, unique philosophy, professional team and reliable quality, we win the worldwide customers' confidence gradually. We directly and indirectly supply our products to more than 50 countries .

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Automatic Generator Motor Stator Coil Winding Inserting Machine
Automatic Generator Motor Stator Coil Winding Inserting Machine
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
