2-Pole Stator Inner Winding Double-Station Mixer Coil Winding Machine
Ningbo Nide Mechanical Equipment Co., Ltd.- Voltage：380V
- Stator Od：50~150mm(Can Be Customized)
- Stack Length：20~60mm(Can Be Customized)
- Speed：0-450rpm Adjustable
- Pole：2poles
- Motor Power：4.5kw
Base Info
- Model NO.：ND-S2PA
- Weight：About 1200kg
- Name：2 Poles Stator Winding Machine
- Automatic：Automatic
- Certification：CE
- Transport Package：Suiitable for Sea Transprotation
- Specification：1050*2300*1750mm
- Trademark：NIDE
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Item
Specification
Wire diameter
0.15-1.3mm
Stator O.D range
50-150mm
Stack length
20-60mm
Pole no.
2 poles
Turn number
0-9999
Spindle speed
0-450 rpm
Motor power
4.5KW
Air supply pressure
5-7 Kg/cm2
Voltage
Three phase AC380V50/60Hz
Weight
1200Kg
Dimension
1050(L)X2300(W)X1750(H)mm
Customerized service
3. Engineers available to service overseas
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.
NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
