Automatic Big Motor Stator Generator Coil Winding Machine
SanShine Electronics (Xiamen) Technology Co., Ltd.- Voltage:220V
- Warranty:12 Months
- After-sales Service:Online Support
- Spindles:1
- Wire Size:0.05~3.8mm
- Spread Pitch:0~9.999mm
Base Info
- Model NO.:SS851BMS
- Spread Width:400mm
- Coil Diameter:500mm
- Demoulding:Pull Core
- Condition:New
- Certification:ISO, Internal
- Automatic Grade:Automatic
- Installation:Desktop
- Driven Type:Electric
- Mould Life:300,000-1,000,000 Shots
- Function:High Precision and Steady
- Transport Package:Customs Approved Wood Box
- Specification:SS851AL
- Trademark:SanShine
- Origin:China
- HS Code:8479811000
- Production Capacity:6000sets,Year
Description
Description : The automatic big motor stator generator coil winding machine (SS851BMS) is a CNC programmable winding machine with the high torsion DC winding motor. This big motor stator generator coil winding machine (SS851BMS) is the best choice for winding and rewinding the big motor stator coil and the generator coils. The Maximum wire diameter of this winder can reach 3.8mm for the small coil. This big motor stator generator coil winding machine (SS851BMS) can be customized according to coil size by requested. Feature : 1. Microprocessor design, easy for program-setting. 2. Stepper motor driven by constant-current power supply, high spreading speed precise winding. 3. "Start Point" could set by key panel or with teachable function. Display Will show the position of spreading head while setting. 4. Wire passing through ceramic rollers prevent enamel from high temperature. 5. Multiple spindles winding synchronal for highest efficiency. 6. Foot-switch connection for better efficiency. 7. Winding parameters and options can be set. Specification :
(SS851BMS) Product DescriptionModel SS851BMS Spindle Number 1 Wire diameter 0.05~3.8mm Spread pitch 0~9.999mm Spread width(traverse) Max. 400mm Finished coil diameter Max. 500mm Winding motor 500W DC Motor Spread motor 4-Phase Stepper Motor Max. speed 2500 RPM Memory 999 Steps Power source AC220V/110V + 10%, 50/60 Hz Dimension(cm) 118x94x66 Our ServicesNet weight 110Kgs
