• Model NO.：HPC-2020
• Productivity：Max: 3200 PCS,H ( L< 300 Mm)
• Brand：Hiprecise
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Function：Abrasion Resistance
• Mould Life：>1, 000, 000 shots
• Customized：Customized
• Transport Package：Wooden Case:1365 Mm ( L )X1220 Mm ( W )X1890 ( H )
• Specification：SGS
• Trademark：Hiprecise
• Origin：Xiamen, China
• HS Code：8537101990
• Production Capacity：20 Sets , Month

Basic Info.

Model NO. HPC-2020 Productivity Max: 3200 PCS/H ( L< 300 Mm) Brand Hiprecise Precision High Precision Demoulding Automatic Heating System Electric Function Abrasion Resistance Mould Life >1, 000, 000 shots Customized Customized Transport Package Wooden Case:1365 Mm ( L )X1220 Mm ( W )X1890 ( H ) Specification SGS Trademark Hiprecise Origin Xiamen, China HS Code 8537101990 Production Capacity 20 Sets / Month

Product Description

Fully automatic terminal crimping Machine(HPC-2020)

1. Both ends crimping.

2. Applicable for home appliance and automobile harness processing.

3. Productivity: MAX: 3200 PCS/H ( L< 300 mm)

4. Adopt JapanTHK linear guide, Japan SUMITOMO precise servo reduction gears to ensure high accuracy and long life of the whole machine.

5. Adopt JapanSMC pneumatic elements, high reliability. Touch man-machine graphics operation screen, visualized and concise.

6. Adopt Japan YOKOGAWA high-performance programmable controlling technology, Japan MITSUBISHI servo and Japan SANYO stepping controlling technology. The machine is stable, reliable and the processing accuracy is high.

7. Adopt the frequency conversion controls terminal crimping machine to accomplish power saving and low noise.

Model	HPC-2020
Cutting Length	40mm-99999mm
Stripping Length	Front end :1.0mm-10.0mm; Rear end:1.0mm-17.0mm
Cutting Accuracy	<±(0.5+0.002*L) (Depending on equipment adjustment and wire materials)
Wire Range	0.03-2.0mm² ( AWG28-AWG14)
Crimping force	2ton
Power	AC220V 50Hz  10A
Air Source	>0.5Mpa
Air Consumption	140NL/min
Dimensions	870mm(W)×1300mm(L)×1450mm(H)
Weight	500Kg
