Bzw-3.0+C+Z Automatic Wire Cut, Strip, Double Ends Terminal Crimping Machine with Tinning and Seal Inserting

Jiangsu Bozhiwang Automation Equipment Co., Ltd.
  • Driven Type：Electric
  • Condition：New
  • Certification：CCC, ISO, CE
  • Warranty：24 Months
  • Automatic Grade：Automatic
  • Wire Range：0.3-6mm2(AWG9#-AWG23#)

Base Info

  • Model NO.：BZW-3.0+C+Z
  • Cutting Length：60-10000mm
  • Stripping Length：0.1-18mm
  • Feeding Speed：Max. 8.0 M,S
  • Crimping Force：30kn
  • Transport Package：Wooden Case
  • Specification：3500*1200*1700mm
  • Trademark：BOZWANG
  • Origin：Jiangsu Changzhou
  • Production Capacity：1000PCS ,Year

Description

Wire range: 0.3-6mm2(AWG9#-AWG23#) (Other size can be special ordered)Cutting length: 60-10000mm (Other size can be special ordered)Cutting precision: ±(0.2%*L+1)mmStripping length: 0.1-18mmFeeding speed: Max. 8.0 m/sCrimping force: 30KNPower: 220V  50HZAir supply: 0.5 Mpa-0.7 Mpa,8m3/hWeight: about 1100kgDimension: 3500*1200*1700mmDetecting ability:  wire knotting, wire lacking, terminal lacking, crimping pressure, air pressure, bare wire , terminal crimping lacking and solderingApplicator range: OTP applicator, European applicator  and pneumatic applicator;It can be installed with CFM,  monitoring the crimping quality during the whole processing and 100% traceability.Function: automatic wire cutting,  wire single  end striping and double end stripping/half stripping/ terminal crimping/seal threading, one end twisting and tinning, another end terminal crimping and seal inserting;Bzw-3.0+C+Z Automatic Wire Cut, Strip, Double Ends Terminal Crimping Machine with Tinning and Seal Inserting
