• Model NO.：BZW-16T
• Crimping Force：160kn
• Rated Power：7.5 Kw
• Stroke：30mm(40mm Is Optional)
• Transport Package：Wooden Case
• Specification：1000 x 650 x 1800 mm
• Trademark：BOZWANG
• Origin：Jiangsu Changzhou
• Production Capacity：1000PCS ,Year

BZW-16T Mute Terminal Crimping Machine-Jiangsu BOZWANG Automation Equipment

1.Upgraded terminal crimping machine with high crimping precision and stability;

2.Multi-functions setting, crimping speed, force and time are adjusted, and also equipped with electronic counter;

3.PLC control, rigid transmission structure, stable crimping  performance, which is suitable for long time and large quantity production;

4.Safe and fast crimping speed, humanized design, standard machine cover, safety grating and other protections to protect the operator;

5.Manual rotation is more easy and convenient to adjust the mould, which is idea replacing product for traditional punch and hydraulic clamp;

6.Cylinder automatic positioning, automatic wire clamping, materials feeding and terminal crimping.

TECHNICAL PARAMETER

Wire range	10-120mm2(AWG6#-AWG0000#)
Crimping force	0.75KW
Rated power	7.5 KW
Average power	3.5KW
Power	380V/50Hz,three phase
Dimension	900 x 1000 x 2000 mm
Weight	900KG
Stroke	40mm (50mm is optional)

      Jiangsu Bozhiwang Automation Equipment Co., Ltd. is a large-scale intelligent wire processing equipment manufacturer in China,located in the center of the beautiful and rich Yangtze River Delta---China's famous industrial equipment manufacturing base Changzhou City, Jiangsu Province.

      The company covers an area of 40,000 square meters and a building area of 45,000 square meters with more than 400 employees,including more than 300 outstanding technicians. The company has successively passed ISO9001, QS-9000, CE certification, TUV certification, and developed a number of products with independent intellectual property rights, and obtained more than 60 invention patents, more than 100 utility model patents and 100 new appearance patents, the technology and comprehensive strength of product research and development ranks the top among the nationwide.

      In the production process, the company strictly follows the ISO:9001 quality standard for daily production and management. It mainly focuses on the automotive, photovoltaic and new energy industries and has developed and produced a series of automatic processing equipment with
high quality, stable performance and high efficiency.

      Mainly include automotive wiring harness/HSD/FAKRA radio frequency wire harness/new energy wiring harness and other related semi-automatic and fully automatic intelligent production lines, automatic double ends terminal machine with seal inserting, automatic ribbon cable terminal machine, automatic single-double-end terminal crimping machine, automatic wire stripping machine,JB box automation equipment, new energy automation equipment, and a complete set of equipment series for various semi-automatic wire harness processing. With the increasing annual output of the company, it has reached an annual output of more than 20,000 sets of intelligent assembly lines and various wire harness processing equipment, and the production equipment has the characteristics of high precision, high degree of automation, and strong supporting performance of the whole machine.
