• Model NO.：T4
• Type：High-speed Chip Mounter
• Mounting Head：4 Groups
• Max Working Size：580*230mm
• Typical Pick and Place Speed：6000~8000cph
• Max Speed：8000cph
• Repeat Accuracy：± 0.015mm
• Position：Visional Position
• Repeat Mount Precision：±0.015mm
• Component Available：Above 0201 and Less Than 38 Mm IC (48mm Camera and
• Programme Method：Automatic Data Import , Video Learning , Keyboard
• Tape Feeder：Optional 8mm, 12mm, 16mm, 24mm Feeder
• Transport Package：Wooden Case
• Specification：ISO9000 ISO14000
• Trademark：TERMWAY
• Origin：Beijing
• HS Code：847989620
• Production Capacity：15PCS,Month

T4
Mounter head
4 heads
Max PCB board
580×230mm
Max move range
640×460mm
Z axis move range
20mm
Typical speed
6000-8000cph
Max speed
8000cph
X,Y axis
precision
+/- 0.001mm
Repeat mount precision
±0.015mm
Position manner
Visional position
Component available
Above 0201 and less than 38 mm IC (48mm camera and lens are selected)
Programme method
Automatic data import / video learning / keyboard input
Transmission
XY-axis high precision ball screw with precision guide+ Industrial dual-belt drive+ grating ruler position
Tape feeder
Optional 8mm,12mm,16mm,24mm feeder
Feeder No.
Can be put 70 pcs of 8MM GFTA-08S feeder,the front and back can be put 35pcs 8mm GFTA-08S feeder (no IC tray)
Can be put 80 pcs of 8MM CF feeder
IC feeder NO.
No more than 2 pcs
Operation system
WINDOWS XP
Compressed air
80psi(0.5Mpa),flue 80L/min
Power
220V,50Hz,5Kw
Weight
700Kg
Dimension
1300×890×1450mm





T4 general characteristics


1,The whole machine adopts Marble terrace structure,  the bottom of the platform and X Y axis gantry structure adopt casting technique,effectively improve SMT production reliability and stability of long-term use


2, Using imported precision square rail,  effectively improve the placement accuracy.



3, Using a unique high-definition optical prism industrial cameras to complete mount high-precision components.



4, With the vision position system, can automatically identify the MARK point, effectively improve SMT production efficiency and placement accuracy.


5, Automatic visional programming,  it is no need to input the coordinates of components by manual, programming is simple, easy to learn for beginners and it is convenient and practical.It can universally import the PCB data, it is most suitable for mass production in middle scale.


6,Standard configure a set of minitype IC tray.



7,The placement configure 8 nozzles.


8,Cost-effective automatic placement machine, it is most suitable for mass production in middle scale and scientific research ,military industrial enterprises high quality usage.


9,The placement configure a set of PCB board transport system, it can seamless connection with stencil printer ,handplace desk and reflow oven.


10,Standard configuration of automatic nozzle replacement system, it can freely change 22 different nozzles.





Optional part:

1, 8mm,12mm,16mm and 24mm automatic feeder of GF type;


2, Nozzle  (6 nozzles, you can customize different nozzles);


3, QS48 component  (mount 48*48mm IC)
