Customized Full Steel Structure with PLC Software Transformer Coil Fast Speed Winding Machine
Shanghai Trihope (PVT) Ltd- Voltage:380V
- Center Height:850 mm
- Center Distance of Spindle:550-800 mm
- Mandrel Torque:Max 200 N.M
- Working Speed:0-220 R,Min
- Mode of Speed Control:Stepless Frequency Control
Base Info
- Model NO.:customized
- Outside:600mm
- Inside:50X90 Square
- Coil Length:750mm
- Rectangular Coil Diagonal Length:800 mm
- Winding Weight:500 Kg
- Automatic:Automatic
- Certification:CE, ISO
- Transport Package:Standard Packing
- Specification:winding machine
- Trademark:Senerge
- Origin:Zhejiang
- Production Capacity:30 Sets,Month
Description
Basic Info.
Model NO. customized Outside 600mm Inside 50X90 Square Coil Length 750mm Rectangular Coil Diagonal Length 800 mm Winding Weight 500 Kg Automatic Automatic Certification CE, ISO Transport Package Standard Packing Specification winding machine Trademark Senerge Origin Zhejiang Production Capacity 30 Sets/MonthProduct Description
GZR-750 Transformer HV Coil Winding Machine1 | Main Parameters | |
1 | Coil parameters | |
1.1 | Center Height | 850 mm |
1.2 | Center distance of spindle | 550~800 mm |
1.3 | Mandrel torque | Max 200 N.M |
1.4 | Working speed | 0~220 r/min |
1.5 | Mode of speed control | Stepless frequency control |
1.6 | Used winding parameters | |
Outside | ≤600mm | |
Inside | 50X90 square | |
Coil Length : | ≤750mm | |
Rectangular coil diagonal length: | ≤800 mm | |
Winding weight: | ≤500 kg | |
1.7 | Total power | About 4.5 kw |
1.8 | Set the maximum number of turns on the counter | Max. Set turns 9999. |
1.1 | Conductor specification enamelled wire: | φ0.2mm~φ3mm |
1.11 | Coil shape | round ,square |
1.12 | Automatic winding | Adjust the min distance of wire in 0.01mm |
1.13 | Power supply | 380v/50Hz |
1.14 | Color | Customized |
2 Layer insulation decoiler | ||
2.1 | Layer insulation installed shaft | 2 sets |
2.2 | Layer insulation outside | ≤φ400 mm |
2.3 | Layer insulation inside | φ76 mm |
2.4 | Layer insulation coil width | 200~800 mm |
2.5 | Decoiler expansion way | inflatable |
2.6 | Decoiler tension | ≤50 N.M pneumatic stepless adjustable |
3 | Automatic winding-rewinding rack | |
3.1 | Mandrel torque | Max 25 N.M |
3.2 | Working speed | 65 r/min |
3.3 | Used winding parameters | |
Outside | ≤350mm | |
Inside | ≥27mm | |
Coil length : | ≤350mm | |
3.4 | Base moving distance | 550mm |
4 | Electric system PLC Control | |
4.1 | Counting Digit | Four(0~999.9) Accuracy 0.1 turn |
4.2 | Operation interface | colorful touch screen |
