• Model NO.：WIND-BLDC-2
• Power：8 W
• Weight：700 Kg
• Dimension：1000X800X2000mm
• After-Sales Service：Engineers Avaiable to Service Overseas
• Transport Package：Wooden Case
• Specification：Middle Size
• Trademark：Wind Automation
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Basic Info.

Model NO. WIND-BLDC-2 Power 8 W Weight 700 Kg Dimension 1000X800X2000mm After-Sales Service Engineers Avaiable to Service Overseas Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/Year

Product Description

Fan Motor BLDC Motor Stator Automatic Inslot Coil Winding Machine
This inslot coil winding machine is suitable for fan motor, brushless motor stator to do coil winding. Machine can wind stators with wire range within 0.1 to 1.2mm. The adoption of a moudle tooling design saves lots of time during tooling change.

(1) Features
High quality level of the winding process
No-loading speed up to 600r/min
Provide customized service4 servo control spindle
Moudle tooling design
High efficiency and production
Precise servo drive control of the wire feeding
2 working stations to do synchronous winding

(2) Specification

Working station	2
Stator ID	10~100mm
Stack length	10-100mm
Stator OD	10- 120mm
Wire range	0.1-1.2mm
Winding speed	600rpm
Power	8 KW
Air source	0.4~0.7 MPa
Power supply	AC 380±10, 50/60HZ
Dimension	1000x800x2000mm
Weight	700KG

(3) Application
It is suitable for fan motor stator, brushless motors.

(4) Operation process
Click mould open button, then put workpiece into the tooling.
Choose auto mode, then select edited product program.
Press start button with two hands, machine will start to do automatic winding.
After winding, machine will automatically reset.
Click mould open button, manual unload workpiece.
