• Model NO.：FC-650C-3
• Type：High-speed Stranding Machine
• Bobbin Size：800
• Usage：Bare Copper Wire,Tinned Wire,Silver Jacketd Wire,
• Color：Sky Blue or Apple Green
• Tension Control Method：Mechanism Friction
• Protection：Machine Will Automaticlly Brake When Wire Inside
• Conduotor Single Wire Dia：0.2-1.7mm
• Conductor Stranding Section Area：10.-16mm2
• Core Wire Single Wire Dia：1.0-4.0mm
• Core Wire Stranding Outer Dia：2.0-8.0
• Direction of Lay：Optional for Right or Left
• Transport Package：Simply Packed
• Specification：ISO9001
• Trademark：FC
• Origin：China
• HS Code：8479811000
• Production Capacity：60set,Month

Basic Info.

Model NO. FC-650C-3 Type High-speed Stranding Machine Bobbin Size 800 Usage Bare Copper Wire,Tinned Wire,Silver Jacketd Wire, Color Sky Blue or Apple Green Tension Control Method Mechanism Friction Protection Machine Will Automaticlly Brake When Wire Inside Conduotor Single Wire Dia 0.2-1.7mm Conductor Stranding Section Area 10.-16mm2 Core Wire Single Wire Dia 1.0-4.0mm Core Wire Stranding Outer Dia 2.0-8.0 Direction of Lay Optional for Right or Left Transport Package Simply Packed Specification ISO9001 Trademark FC Origin China HS Code 8479811000 Production Capacity 60set/Month

Product Description

In the year 2018newly developed machine:FC-650C-2 high speed bunching machine,it has the following functions:


1. High-intelligent tension control system:with high precision enclosed tension control system,make take up tension is stable from beginning to end.
2. Germany ZF hysteresys clutch:instead of magnetic powder clutch.
3. Automatic oil adding system:can setting on PLC programme,cannot effect by environment,save worker time and high efficiency.
4. Main shaft test temp device:when main shaft is in abnormal heat,its temp is not in normal,machine will automatically alarm and stopped.
5. Main body of machine and internal is separated.Lower noise and more environmental.
6. Internet control:many sets of bunching machine working condition can sums into one computer or mobile,so you could check the working condition at any time,such as machine speed,wire specification,linear speed,output,machine maintenance and so on;and could on line analyse machine,reduce production and maintenance fees;
