• Model NO.：HC-515
• Stripping Length：0.5mm--30mm
• Cutting Length：0-64m
• Conduit Diameter：10mm
• Wire Feed Speed：Variable
• Productivity(PCS/H)：15000-20000PCS,H
• Type：Automatic
• Conductor Sectional：0.1mm2-6.0mm2
• Transport Package：Wooden Box
• Specification：L420*W415*H225
• Trademark：Hechang
• Origin：China
• HS Code：8479899990

Model

HC-515

Outer dimensions

L418mm*W358mm*H338mm

Weight

35kg

Power supply

220V

Power consumption(220V)

400W

Cutting length

0.5mm--99999.99mm

Cutting tolerances

±( 0.1+0.0005×L )mm 2 L : indicates a cutting length.

Applicable wires

Type

Spring wire , steel iron wire , copper wire, PVC tube, rubber pipe.

, teflon tube,steel ,wire ,AVSS,VSF, IV, KV, UL,Teflon , Glass Wire,sleeving, hear shrink sleeve, etc

O.D

Max φ9mm

Wire feed speed

variable

Productivity(pcs/min)

80pcs/min

Drive supply

Stepping puls motor/Air cylinder  four-wheel drive,independent drive box driver

Changzhou Hechang Machinery Co;Ltd is a Hi-tech professional manufacturer, Providing all-rounded solutions to wiring harness processing area for the customers from Electrical Appliances, Automotive,New Energy, Industrial Control Automation, instrument and apparatus,Medical ,Electric control cabinet , lighting and so on .

Our main products included Fully-automatic wire cut strip crimp machine, wire cut strip machine, Terminal crimping machine, wire cut strip and inkject marking ,wire tinning machine , Seal insertion, Applicators for terminal crimping, quality assurance , peripherals and other special wiring harness processing electronic equipments.


Changzhou Hechang defines an OEM (Original Equipment Manufacturer) as an entity or organization that integrates a customized or embedded Changzhou Hechang product in its own unique solution for sale to its customers. The proof of this concept is that the Changzhou Hechang product must be significantly transformed. The OEM The firm side uses its own company logo and brand name on its solution and it markets, sells and providing technical and warranty support directly to its customers. Just tell us your ideas and We can manufacture 3 wheel adult electric motorcycle as per the special requirements of our clients.we will help to make out the good design on motorcycle and send you finished files for confirmation according to your demand and our experience.
