• Model NO.：HC-20PX
• Display：Chinese,English Interface
• Weight：350kg
• Stripping Length：0.5-8mm
• Terminal Pressure：Standard 2.0t
• Rated Power：2.5kw
• Wire Size：AWG#26-AWG#18 6p-12p Flat Cable
• Transport Package：Wooden Box
• Specification：1000*750*1500 mm
• Trademark：Hechang
• Origin：China
• HS Code：8479899990
• Production Capacity：100PCS,Year

Basic Info.

Model NO. HC-20PX Display Chinese/English Interface Weight 350kg Stripping Length 0.5-8mm Terminal Pressure Standard 2.0t Rated Power 2.5kw Wire Size AWG#26-AWG#18 6p-12p Flat Cable Transport Package Wooden Box Specification 1000*750*1500 mm Trademark Hechang Origin China HS Code 8479899990 Production Capacity 100PCS/Year

Product Description

Product Description
It is mainly used for crimping :PH.XH.EH,ZH etc Color flat cable wiring harness  communication terminal Flat cable terminals used in SCN,SM,VH,Dupont etc.Automated production to ensure the fixed-length cutting, peeling precise and terminal pressure on balance, make the wiring harness terminal pressure and tidy, good consistency and quality of the products is very stable.The machine adopts imported servo motor drive, no matter how much the cable harness number , terminal precise pressure control to ensure that the wiring harness , cable conduction performance positioning is more accurate , real stable , precise effect high speed, low noise.Fully automated production, saving labor costs : from fixed-length cut into the cable , stripping sub-line , pressure double ( single ) head terminals , the process is completed automatically , without manual involvement .High efficiency: 18 k terminal pressure per hour, the equipment can work 24 hours a day.lectric adjustable, adjust length and sub-line length, stripping length, easy to operate, stable, efficient,


Feature
Broader processing range with a diversity of options and solutions
Cutting to length and stripping of stranded wires
high precision,greatly improving efficiency.
Intuitive, flexible and simple User-friendly english operation
Extremely low maintenance



Technical Data

Mode	HC-20PX
Description	Fully-automatic flat cable double ends terminal crimping machine Cutting stirpping spliting and both ends crimping
Dimension	1000L*750W*1500H(MM)
Weight	350KG
Display	LCD color touch screen
Operation mode	Automatic movement + receive running
Adjust blade	electric adjustable
Drive mode	Servo + stepper
Blade material	Rapid Steel
pneumatic parts	Original AriTAC and original SMC
Lead screw and guide rail	Original HIWIN
Cutting length	90-9999MM
Tolerance	±0.01MM
Wire width	Max28mm width /20pin
Stripping length	0.1-8MM
Wire size	OD 0.6mm- 2.5mm/single wire
processing capability	12000-14000pcs terminals/h   ,
Terminals pressure	Standard 2.0 T
Air pressure	5KG At least 5kg, dry and clean air
Power	AC220V
rated power	2.5KW
detection device	Lack of line detection , lack of terminal testing, crimping testing, air testing, voltage detection



FAQ

 About delivery term

Question : what's the delivery term for doing business with you ?

Answer : we send the shipment in FOB term. The term of CIF and CFR are acceptable which depends on preference of clients

About lead time

Question : what's the leading time after placing the order

Answer : often ,it takes 1 days after getting your conformation  .

however, it depends on production schedule ( the timing clients place order ) and the complication of machines .

About payment term

Question: what's the payment term ?

Answer : by T/T in advance, paypal, western union, Mainly T/T



Packaging&shipping
By express: DHL, UPS, FEDEX.EMS

We will search the most economical and reliable shipping company to transport the goods safely.

By air: when your order is more than 100kg which will be more economical than express

By sea: when your order is large quantity, we can help you to deliver the goods by sea

Port:Shanghai,Ningbo,Shenzhen




Certifications

Company Information

Changzhou Hechang Machinery Co;Ltd is a Hi-tech professional manufacturer, Providing all rounded solutions to wiring harness processing area for the customers from Electrical Appliances, Automotive, Industrial Control Automation, Instruments , Meters industries.Medical ,Electric control cabinet , LED lighting , Communications Industry and so on.

Our main products included Fully automatic terminal crimping machine, Digital wire cutting & stripping machine, Terminal crimping machine, cable/wire printing inkject marking machine ,Applicators for terminal crimping, Industrial robot and other special wiring harness processing electronic equipments .
