Torch SMT LED Light Making LED Mounting Automatic LED Pick and Place Machine L8 in LED Line

Termway (Beijing) Precision Technology Co., Ltd.
  • Condition：New
  • Speed：Medium Speed
  • Precision：High Precision
  • Certification：CCC, UL, RoHS, ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：L8
  • Type：Medium-speed Chip Mounter
  • Max Circuit Board Size：1200*300mm
  • Weight：500kg
  • Dimension：2600× 760× 1500mm
  • Transport Package：Plywood Case
  • Specification：ISO
  • Trademark：TERMWAY
  • Origin：Beijing, China
  • HS Code：8479896200
  • Production Capacity：20 PCS,Month

Description

1200*300mmMax moving rangeX axis 1500mm, Y axis410mmMax moving range of Z axis15mmTypical Mounting speed13000-14000cph14000-18000cphMax mount speed18000cph22000cphMount accuracy+/-0.05mmPosition methodVisual position/Machinery positionComponent available0603 and above SMD component and LED, SOT, SOPProgramme methodAutomatic data import/ video study/ keyboard inputBelt feeder8mm, 12mm, 16mm and 24mmFeeder num6 pcs of GF series feeder can be set (12 pcs feeders are optional)8pcs of GF series feeder can be set (16pcs feeders are optional)Operation systemWINDOWS XPCompressed airlarge production  should use industrial air pumpPower supply220V, 50Hz, 4.5 KwWeight500Kg700KgDimension2600× 760× 1500mm
