Custmoized Automatic Electric Motor Stator Coil Winding Machine for 3 Phase Motor Manufacturing

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：380V
  • Name：Stator Coil Winding Machine
  • Wire Diameter：0.17-1.2mm
  • Max Winding Speed：2000rpm
  • Power：380V,50,60Hz 7kw
  • Weight：1100kg

Base Info

  • Model NO.：RXL1-160A
  • Dimension：1800 X1100 X2200mm
  • After-Sales Service：Overseas Service Center Available
  • Machine Color：Ral9010 or as Per Customer Requirement
  • Max Stator Od：160mm
  • Max Stack Height：100mm
  • Automatic：Automatic
  • Certification：CE
  • Transport Package：Wooden Case
  • Specification：ISO9001
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479811000
  • Production Capacity：100 Sets,Year

Description

Dimension: L1800*W1100*2200mm


Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Custmoized Automatic Electric Motor Stator Coil Winding Machine for 3 Phase Motor Manufacturing
Custmoized Automatic Electric Motor Stator Coil Winding Machine for 3 Phase Motor Manufacturing
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
