Starter Pole Coil Winding Copper Strip Winding Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
- Transport Package：Wooden Case
Base Info
- Model NO.：WIND-PCW-F2
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-PCW-F2 Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Starter Pole Coil Winding Copper Strip Winding Machine
The winding machine can automatically wind the field coil with below process continuously,
Automatic wire feeding→ wire straightener → bend starting terminal→ wire feeding I, →bending→ wire feeding II→ press wire to tooling→ forming→ paper feeding and twisting winding→Wire cutting→ paper cutting→ twisting forming→unloading,
(1)Specifications
| Productivity | 12s/pc |
| Power Supply | AC 380V |
| Power | 1.5KW |
| Weight | 600KG |
| Dimension | 1500x800x1800mm |
(2) Application
Suitable for various kinds of starter motor with rectangular wire coil.
(3) Features
Short re-adjusting time
PLC controlled working operations
Completely automated winding process of the magnetic field coil
Auto winding, straightening, bending and twisting
This machine can be customized accordingly
Self-diagnostic troubleshooting system
No skilled operator required
