Fully Automatic 8 Working Stations Stator Coil Winding Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty:12 Months
- Color:Customized
- After-Sales Service:Engineers Avaiable to Service Overseas
- Condition:New
- Customized Service:Provided
- Transport Package:Wooden Case
Base Info
- Model NO.:WIND-8VW
- Specification:Middle Size
- Trademark:Wind Automation
- Origin:China
- HS Code:8479811000
- Production Capacity:100 Sets,Year
Description
Basic Info.
Model NO. WIND-8VW Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Fully Automatic 8 Working Stations Stator Coil Winding MachineThis machine adopts turntable mechanism. After one coil wound, the turntable will rotate to swith working station. Therefore, four station will do winding, while the other four wait for unloading, which greatly improves the working efficiency.
(1) Specification
Wire diameter | 0.2~1.0mm |
Winding head | 4 |
Station | 8 |
Stack length | Max 70mm |
Winding Speed | Max 3000r/min |
Air pressure | Min 0.6Mpa |
Power supply | 380V 7KW |
Weight | About 2300KG |
Dimension | 1900x1400x2200mm |
(2) Feature
4 winding head 8 working station
Manual unloading coils after winding
Rotation and indexing controlled by servo system
No distinct vibration or noise during winding
Automatically stop if wire is run out
All winding parameter programmable on touch screen
(3) Application
This machine is suitable for 2 poles, 4 poles and 6poles coils winding.
(4)Operation step
Thread wire into the machine
Connect the power and air source
Turn on the machine, and press "reset" button to reset the machine
Put the winding form on the indexing plate
Press "cut wire"
Press "start" button by two hands, machine will automatically wind the stator.
