Multi Layer Automatic Coil Winding Machine for Micro Pump Motor

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：220V
  • Warranty：12 Months
  • Diameter of Wire：0.08~1.0mm
  • Wire Amplitude：0~30mm
  • Max Winding Diameter：250mm
  • Effective Distance Between Winding Shaft：550mm-700mm

Base Info

  • Model NO.：RX1-160
  • Rotation Speed：3200r.p.m
  • Input：220V,50Hz
  • Air Source：0.5-0.8MPa
  • Machine Productivity：1500PCS, 8 Hours
  • Dimension：1550mmx1250mmx1300mm
  • Weight：750kg
  • Demoulding：Manual
  • Heating System：No Heating
  • Condition：New
  • Customized：Customized
  • Automatic：Automatic
  • Certification：CE, ISO
  • Transport Package：Pallet
  • Specification：750
  • Trademark：750kg
  • Origin：Chine
  • Production Capacity：60sets,Year

Description

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Multi Layer Automatic Coil Winding Machine for Micro Pump Motor
Multi Layer Automatic Coil Winding Machine for Micro Pump Motor
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
