Fiber Optical Outdoor Cable Extrusion Machine in Wire and Cable Manufacturing Line. Fibre Optic Drop Cable Sheath Wire Extrusion Machine~
Wuxi Longterm Machinery Technologies Co., Ltd.- After-sales Service：Provided
- Driven Type：Motor
- Condition：New
- Warranty：12 Months
- Screw：Double-Screw
- Application：Fiber Optic Cable Extruder
Base Info
- Model NO.：WLT
- Nitrogen Depth：0.5~0.7mm
- Length to Diameter Ratio：25:1
- Hardness：>940
- Take-up Tension：5n~30n(Adjustable)
- Take-up Reel Size：Pn280,Pn630
- Center Height of Production Line：1000mm
- Production Line Structure Speed：200m,Min
- Extrusion Molding Machine：Sj65-25
- Steel Wire Reel Shaft Hole Size：80mm
- Load-Bearing：600kg
- Pay-off Structure Speed：Max200m,Min
- Wire Reel Size：630~800mm
- Optical Fiber Diameter：0.254mm
- Axis Runout Accuracy：0.05mm
- Transport Package：Standard Seaworthy Package
- Specification：customized
- Trademark：HLT
- Origin：China
- HS Code：847720900
- Production Capacity：400sets,Year
Description
Application:
The frame is a cabinet frame structure; it is driven by an AC frequency conversion controller, and a transmission mechanism composed of a frequency conversion motor and a reducer provides the unwinding power; the moving mechanism composed of a lifting motor and a reducer provides the unwinding power; the cylinder top is used for clamping and loosening The pay-off centering mechanism can effectively prevent the jitter caused by the wire obliquely pulled out; the pay-off tension control dance wheel is equipped with the air cylinder and precision pressure regulating valve to control the moving pulley. The moving pulley track adopts high-quality linear slide rails and sliders, and the equipment layout is reasonable and compact; the start and stop of the line are controlled by the localTechnical Parameters:
1,Q: What is your main brand for the electrical and mechanical parts?
A: China famous brand
2, Q:could we appoint the parts brand?
A: Yes, ABB, SIEMENS, or theirs that you like.
3, Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge
4, Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge
5, Q: could you do the design for the whole plant
A: Yes , we can.
6, Q: could you offer the production process design
A: Yes , we can.
7, Q: what is the difference with other supplier?
A: what we could offer to other customer is not only the machine itself, also we could offer: factory design, production process design , QC control and education and assist machine and raw material offering .
8.Q:What's the payment terms?
A:T/T,30% deposit and 70% balance before delivery.
9, Q:How long the guarantee:
A: one year and charge for repair the whole life.
| Enable us to give you a better quotation, please kindly provide the parameter below: |
| 1. Coil diameter (we need to know the take up and pay off machine size)? |
| 2. Extrusion speed? |
| 3. Extrusion thickness? |
| 4. What is material of outer sheath.(PVC or PE or HDPE or MDPE or TPU? |
