• Model NO.：Neoden4
• Automatic Grade：Automatic
• Type：High-speed Chip Mounter
• Tape Width：8mm, 12mm, 16mm, 24mm
• Vacuum Pump Qty：4(Built-in)
• Placement Head Qty：4PCS
• Power Supply：220V 50Hz
• Packing Size：94*74*60cm
• Rotation：+,-180
• Component Size：Smallest Size 0201 Largest Size Tqfp240
• Feeder Capacity：Tape Reel Feeders 48
• Vibration Feeders：5
• IC Tray：5
• Transport Package：Fumigation-Free Wooden Box
• Specification：CE
• Trademark：NeoDen
• Origin：Zhejiang
• HS Code：84798962
• Production Capacity：200PCS,M

Overview Detailed Photos



1. Vision system (an up-looking camera and a down-looking camera) identifies and calibrates the different components simultaneously, and tremendously improves the accuracy of placement from 0201 to BGA;
2. Auto rails help to achieve continuous placement and solve the problem of long LED strip, such as 0.8m, 1.2m and 1.5m LED strip;
3. Auto electric feeders greatly reduce the feeding deviation;
4. General conveyor is supported, so a SMT production line can be setup, which is more time-saving and labor-saving.
5. Four placement heads help to pick up and calibrate components at the same time.
6. The device supports remote system upgrade, NeoDen provides a life-long system upgrade service without charge.Product Parameters



Our Advantages

After Sales Service

FAQ

Q1: Do you provide software updates?
A: Customers who buy our machine,we can offer free upgrades software for you .

Customers' Cases



NeoDen in Exhibitions



NeoDen in RussiaNeoDen in ArgentinaNeoDen in USA
