• Model NO.：Jaguar F8
• Size：5000*1320*1490mm
• Color：Gray
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Customized：Customized
• Transport Package：Wooden Case
• Specification：CE
• Trademark：Jaguar
• Origin：Shenzhen, China
• HS Code：8515190000
• Production Capacity：100 Sets,Month

ModelJaguar F8GENERALDimension(L*W*H)5050*1320*1490mmweight Approx. 1850KG/1950KGnumber of heating zonesUp8 /Bottom8length of heating zones3120mmnumber of cooling zonesup2(cool air conversion)exhaust volume10m³/min ×2 ExhaustsConveyor systemrails structuresubsection integrated typeMax. width of PCB400mm(option 460mm)range of rail width50-400mm(option 50-460mm)components clearancetop 30mm/bottom 25mmconveyor directionL-R(Option R-L)fixed rails sideFront Rail Fixed(Option: Rear Rail Fixed)PCB transmission modeAir-Reflow=chain+mesh,
N2-Reflow=Chain+mesh(option)conveyor height900±20mmconveyor speed range300-2000mm/minauto/manual lubricationstandardcontrolling system Electric supply3 phase 380V 50/60 HZ(3 phase 220 V 50/60 HZ)starting powerapprox 40KW/42KWnormal power consumptionapprox 7.5KW/8KWwarming timeapprox 20 minstemp. setting rangeroom temp. -300ºCtemp. control methodPID Close Loop Control+SSR Drivingtemp. control precision±1ºCtemp. deviation on PCB±2ºC(by Jaguar Board Test Standard)nozzle platealuminilum alloy platedata storageprocess data and status storage(80GB)abnormal alramabnormal temp. (extra-high/extra-low temp. )board dropped alarmTower light: yellow-warming, green-normal, red-abnormalcooling systemcooling methodAir Oven: Forced Air. Nitrogen Oven: Water ChillerProduct Features:
1. The brand computer + Siemens PLC intelligent control system, high precision temperature control is ± 1-2 ºC (if the computer crash accident, and can realize off-line work, do not affect production) and to ensure that the control system is stable and reliable;
2. Windows operating interface, powerful, simple operation,
3. On the cylinder body open automatic lifting machinery, ensure safe and reliable;
4. Equipped with mesh belt tensioning device, transport smoothly and no shaking, deformation, ensure smooth PCB transport; Synchronous guide transmission mechanism (and automatic SMT machine online connection), ensure that guide adjustable wide precision and high service life;
5. Automatic control lubrication system, through the set come on time and fuel charge, automatic lubrication transmission chain;
ºC6. All heating zone all by computer PID control (upper temperature zone and lower temperature zone implementation independent temperature control, can divide temperature area alone. Can open division heating, in order to reduce starting power);
7. Net/chain transmission by computer to carry out the whole closed loop control, can meet different kinds of PCB production at the same time
8. With fault sound and light alarm function;
9. With leakage protector, ensure that the operating personnel and control system security;
10. The built-in UPS and automatic delay shutdown system to guarantee the PCB and return welder in power or overheat not damaged;
11. The German ERSA world leading microcirculation heating mode, and the upper and lower independent air microcirculation system, temperature uniformity and thermal compensation high efficiency, high efficient supercharged accelerated air duct, greatly improve the circulating hot air flow, temperature quickly (about twenty minutes), thermal compensation for high efficiency, high temperature welding and curing;
12. The upper and lower every temperature zone with independent temperature inductive sensor, real-time monitoring and compensation every temperature zone temperature balance;
13. Have password administration of the operating system, to prevent the irrelevant personnel changes to the process parameters, operation records management traceability process parameters change process, improve the management convenient. For storing user existing temperature speed setting and Settings of the temperature curve, and can be used for all data and curve printing;
14. Integrated control window, the computer switch, test curve, print curve and data transmission are easily operation, humanized design. Equipped with three-channel temperature curve online testing system, may at any time to check welding objects by the actual temperature curve (without the other match temperature curve tester);
15. From international technology quick cooling system, use a magnifying glass type efficient rapid cooling, cooling speed can reach 3.5 ~ 6 ºC / SEC, management is very convenient; The outer forced cooling device, ensure that spot crystal effect (Option selected items, the standard configuration for forced natural air cooling).
