2021 Year Save Power Lead Free Reflow Oven for PCBA with Siemens PC+PLC Control
Shenzhen Jaguar Automation Equipment Co., Ltd.- Condition:New
- Certification:ISO, CE
- Warranty:12 Months
- Automatic Grade:Automatic
- Name:Lead Free Reflow Oven
- Number of Heating Zones:Up12 ,Bottom12
Base Info
- Model NO.:Jaguar F12
- Length of Heating Zones:4640mm
- Conveyor Speed Range:300-2000mm,Min
- Precision:Precision
- Heating System:Electric
- Customized:Customized
- Transport Package:Wooden Case
- Specification:CE
- Trademark:Jaguar
- Origin:Shenzhen, China
- HS Code:8515190000
- Production Capacity:100 Sets,Month
Description
ModelJaguar F12 GENERAL Dimension(L*W*H) 6120*1320*1490mm weight Approx. 2450KG/2550KG number of heating zones Up12 /Bottom12 length of heating zones 4640mm number of cooling zones up2(cool air conversion) exhaust volume 10m³/min ×2 Exhausts Conveyor system rails structure subsection integrated type Max. width of PCB 400mm(option 460mm) range of rail width 50-400mm(option 50-460mm) components clearance top 30mm/bottom 25mm conveyor direction L-R(Option R-L) fixed rails side Front Rail Fixed(Option: Rear Rail Fixed) PCB transmission mode Air-Reflow=chain+mesh, N2-Reflow=Chain+mesh(option) conveyor height 900±20mm conveyor speed range 300-2000mm/min auto/manual lubrication standard controlling system Electric supply 3 phase 380V 50/60 HZ(3 phase 220 V 50/60 HZ) starting power approx 60KW/62KW normal power consumption approx 11.5KW/12KW warming time approx 30 mins temp. setting range room temp. -300ºC temp. control method PID Close Loop Control+SSR Driving temp. control precision ±1ºC temp. deviation on PCB ±2ºC(by Jaguar Board Test Standard) nozzle plate aluminilum alloy plate data storage process data and status storage(80GB) abnormal alram abnormal temp. (extra-high/extra-low temp. ) board dropped alarm Tower light: yellow-warming, green-normal, red-abnormal cooling system cooling method Air Oven: Forced Air. Nitrogen Oven: Water Chiller
