• Model NO.：customized
• Outside Diameter：600 mm
• Inside Diameter：100 mm
• Coil Length：1000 mm
• Winding Weight：500 Kg
• Total Power：5 Kw
• Original：China
• Automatic：Automatic
• Certification：CE
• Transport Package：Standard Packing
• Specification：4000(L) 2700(W) 1400(H) mm
• Trademark：Senerge
• Origin：Zhejiang
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. customized Outside Diameter 600 mm Inside Diameter 100 mm Coil Length 1000 mm Winding Weight 500 Kg Total Power 5 Kw Original China Automatic Automatic Certification CE Transport Package Standard Packing Specification 4000(L) 2700(W) 1400(H) mm Trademark Senerge Origin Zhejiang Production Capacity 30 Sets/Month

Product Description

Product Detail:

HV winding machine consists of winding host, auto alignment wire device, layer insulation supply device, round wire and flat wire tension adjustable pay-off stand, pneumatic system and PLC control system, servo motor system and touch screen man-machine interface, etc.

Feature:

HV wire winding machine is with a high degree of automation, the machine is full function and powerful. To guarantee winding compactness of axis and width, especially design for rectangular coil winding.

No.	Item	Parameters
1	Center height	860 mm
2	Center distance of spindle	1100 mm
3	Mandeill torque	Max 400 N-M
4	Rotation speed	0-450 r/min
5	Mode of speed control	Stepless frequency control
6	Used winding parameters:	Outside diameter (O.D.)    ≤ 600 mm          Inside diameter (I.D.)       ≥ 100  mm        Coil Length ( L )         ≤ 1000 mm       Winding weight:     ≤ 500 kg
7	Total  Power	5 kW
8	Max. Set   turns	0--9999.9
9	Conductor specification	Cu.Wire Size dia     Φ0.3 mm-Φ5 mm Fate Cu. Wire          ≤ 30 mm2
10	Automatic wire pitch setter	Can set minimum wire pitch of 0.01 mm
11	Counting mode	5-digital display, can set total turns and set turns in 20 times, reverse counting available, no losing data in the event of power-off.
12	Power supply	Three-phase AC 380 V, 50 HZ
13	Weight	2500kg
14	Outline dimension	4000(L)×2700(W)×1400(H) mm
15	the temperature of  working shop	0-45°C
