• Model NO.：T200N
• Welding Time：3min±1min
• Heating Supply：Infrared Ray + Hot Air Convection
• Temperature Curve：It Can Be Set, Adjusted and Tested According to Th
• Cooling System：Transverse Flow Equal Cooling
• Rated Voltage：AC Single-Phase, 220V;50Hz
• Rated Power：3.8kw
• Mean Power：1.6kw
• Temperature Control Segment：40 Segment .The Segment Can Be Set in Computer Acc
• Dimension：Length*Width*Height 820*460*310mm
• Transport Package：Wooden Case
• Specification：CE
• Trademark：TORCH
• Origin：Beijing, China.
• HS Code：847989620
• Production Capacity：100 Sets,Month

Item
Parameter
Temperature control segment
40 segment .The segment can be set in computer according to the actual requirement.
Temperature-zone numbers
Single-zone and multi-segment
Temperature control system
PC control system ,SSR non-contact output.
Temperature accuracy
±2ºC
Warm-up time
3min
Temperature range
Room-temperature -360 ºC
Heating supply
Infrared ray + Hot air convection
Effective working table area
230mm * 270mm (less than A4)
Welding time
3min±1min
Temperature curve
It can be set, adjusted and tested according to the actual requirement .
Cooling system
Transverse flow equal cooling
Rated voltage
AC single-phase ,220V;50Hz
Rated power
3.8KW
Mean power
1.6kw
Weight
45kg
Dimension
Length*width*height 820*460*310mm







Unique Feature:

1)  "T200N"   with Purifying and Filtering gas function!

Exhaust outlet  with  "Actovated carbon and can filter the dangerous fumes,  can't influence health and Environment-friendly!


2) " T200N"    "+"  means that "With On-line temperature testing function".


3)   T200N  with Exhaust outlet in the back of machine


4)   "T200N" can realize RS485 and USB  Interface!

5)    T200N   with "Automatic Sliding door " to  ensure the convey PCB Board Speed more stabely and ensure the Component on PCB Board won't slide!
This's feature also our patent!   Others supplier are "Sliding door by Manual ", can't ensure the convey PCB Board Speed and welding effect!

6)   "T200N"   need refular cleaning every week.  Generally speaking,  work life can reach 10years is no problem!


7)  With 40Segments temperature and with have 4Heating stage, Preheating---Constant temperature---Heating---Cooling;


8)  Standard configuration : with 3Pcs heting tube, 3group fuse is available.
