Economic Type Machine for Armature Coil Winding Machine
Shanghai Wind Automation Equipment Co., Ltd.- Voltage：220V
- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
Base Info
- Model NO.：WIND-SAW
- Automatic：Automatic
- Transport Package：Wooden Case
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-SAW Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Economic Type Machine for Armature Coil Winding Machine
This machine is used to do armature coil winding. Hooking should be done manuall. Clamping, winding, indexing will be done by machine automatically.
(1) Application
Suitable for automobile motor, motorcycle motor, house appliances series excited motor, power tool motor and various kinds of PM DC micro motor.
| Wire Diameter | 0.08-1.08mm |
| Flyer Speed | 0-1400r/min |
| Flyer No. | 2 |
| Turn No. | 0-9999 |
| Power | 0.8KW |
| Power supply | 220V±10%, 50HZ |
(3) Information needed for inquiry
1. Armature lamination drawing
2. Armature assemble drawing
3. Armature stack drawing
4. Armature winding diagram drawing
5. Commutator drawing
6. Required productivity
7. Other technical requirement
