Armature Winder Rotor Slot Coil Winding Machinery
Shanghai Wind Automation Equipment Co., Ltd.- Voltage：220V
- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
Base Info
- Model NO.：WIND-2B-TD
- Automatic：Automatic
- Transport Package：Wooden Case
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-2B-TD Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Armature Winder Rotor Slot Coil Winding Machinery
This machine is suitable for slotted armature with OD within 20~90mm.
Machine Operation1)Put the armature on the tooling
2)Then press the start button.
3)Machine will wind the armature automatically
4)Unload wound armature
Specification
| Wire range | 0.2~1.2mm |
| Armature OD | 20~90mm |
| Stack height | 10~130mm |
| Commutator OD | 8~60mm |
| Movement | Jog/auto |
| Slot No. | Odd/Even |
| Turn No. | 0~9999 |
| Flyer speed | 0~2000rpm |
| Power supply | AC 220V 50/60HZ |
| Air source | 5~7kg/cm3 |
| Power | 3.5KW |
| Weight | 830KG |
| Dimension | 1530x1280x1650mm |
Feature
For riser type commutator
With medium and big wire diameter
Manual loading and unloading
Can work as a stand-alone machine or integrated into a production line
All winding parameter programmed on touch screen
This machine is suitable for slotted type armature with riser type commutator.
