Motorcycle Motor Armature Winding Machine Coil Winder
Shanghai Wind Automation Equipment Co., Ltd.- Voltage：220V
- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
Base Info
- Model NO.：WIND-2-TD
- Automatic：Automatic
- Transport Package：Wooden Case
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-2-TD Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Motorcycle Motor Armature Winding Machine Coil Winder
This winding machine is suitable for high-speed winding of medium and big wire diameter armature with hook-type commutator. The winding process is done by two flyers. It can be connected with a production line to realize online automatic production. It can save up to 99 sets armature parameter.
(1) Specification| Wire range | 0.15~1.26mm |
| Armature OD | 20~90mm |
| Stack height | 10~130mm |
| Commutator OD | 8~50mm |
| Movement | Jog/auto |
| Slot No. | Odd/Even |
| Turn No. | 0~9999 |
| Flyer speed | 0~2000rpm |
| Power supply | AC 220V 50/60HZ |
| Air source | 5~7kg/cm3 |
| Power | 3.5KW |
| Weight | 830KG |
| Dimension | 1450x1050x1650mm |
(2) Application
This machine is widely used in the winding of DC and series excited motor rotors.
(3)Machine configuration
Mitsubishi PLC
Delta servo control system
Touch screen
Airtac pneumatic system and air source treatment
Fully automatic feeding device (can be connected with production line)
Hysteresis tension control unit
HIWIN linear guide
