• Model NO.：WIND-STR
• Automatic：Automatic
• Transport Package：Wooden Case
• Specification：Middle Size
• Trademark：Wind Automation
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Basic Info.

Model NO. WIND-STR Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/Year

Product Description

Rotor Winder Armature Slot Coil Winding Machinery

This armature winder is a high seed flyer winding machine for hook type commutator armature, like Mixer,Vacuum cleaners, Hammers,Power tool.

(1) Specification

Power supply	AC380V±10%  50/60HZ
Air resource	4~6kg/cm2
Weight	about 1250kg
Dimension	2000mm×1000mm×1800mm
Total power	4KW
Armature OD	20~85 mm
Commutator OD	8~40mm
Shaft OD	3~15 mm
Shaft length	Max 250mm
Wire diameter	0.16~1.2 mm
Slot number	Even number
Turn No.	0~9999
Stack length	10~70 mm
Winding speed	0~2500rpm
Winding motor power	1.5KWX2
Angle detecting speed	0~3000rpm
Angle detecting motor power	0.75KWX1

(2)Feature
For hook type commutator
High quality level of winding
Manual loading and unloading
For medium and big wire diameter
Automatic feeding, winding, indexing and wire cutting
All winding parameter programmed on touch screen

(3) Application
Suitable for mixer,vacuum cleaners, hammers,power tool.

(4)Machine configuration
Mitsubishi PLC
Mitsubishi or Panasonic servo motor control system
5.7'' colorful touch screen system
SMC Cylinder
