• Model NO.：WIND-WZE
• Dimension：1350X630X1130mm
• After-Sales Service：Engineers Avaiable to Service Overseas
• Transport Package：Wooden Case
• Specification：Middle Size
• Trademark：Wind Automation
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Basic Info.

Model NO. WIND-WZE Dimension 1350X630X1130mm After-Sales Service Engineers Avaiable to Service Overseas Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/Year

Product Description

Ceiling Fan Stator Coil Winding Machine
This ceiling fan winding machine is fully automatic, winding, arraying, indexing are all done by machine.Two winding stations ensures two coils can be wound at the same time.

(1) Specification

Wire diameter	0.05~0.45mm
Stator O.D	10~163mm
Slot number	≤24 slots
Stack height	6~30mm
RPM	Max 2500RPM
Voltage	220v/50Hz
Power	1.5 KW
Weight	435Kg
Dimension	1350X630X1130mm

(2) Application
This ceiling fan coil winding machine is capable of producing coils for frequency conversion alternator and generator stator.

(3) Features
Two winding stations
Micro computer controlled operation
Wire arraying and indexing controlled by stepping motor
Winding controlled by frequency converting motor
