Auto PCB Reflow Oven Soldering Machine with Temperature Control (A6/8)
Shenzhen Jaguar Automation Equipment Co., Ltd.- Condition：New
- Certification：CCC, RoHS, ISO, CE
- Warranty：12 Months
- Automatic Grade：Automatic
- Installation：Vertical
- Number of Cooling Zones：1
Base Info
- Model NO.：Jaguar A6,A8
- Standard Color：Computer Grey
- Electric Supply Required：5 Line, 3phase, 380V 50,60Hz
- Conveyor Speed Range：0-1500 mm,Min
- Precision：Normal Precision
- Heating System：Electric
- Customized：Non-Customized
- Transport Package：Vacuumed and Sealed in Plywood Crate
- Specification：CE
- Trademark：Jaguar
- Origin：Shenzhen, China
- HS Code：8515190000
- Production Capacity：100 Sets,Month
Description
5 line 3 phase 380V 50/60 HZWarming time Approx. 20 mins Heating time Up:hot air; bottom: IR Temperature setting range Room temp. -350 Degrees Celsius Control system PID+SSR/PLC+PC Temperature control method PID Close loop control&SSR Driving Temperature control precision ±1.0 Degrees Celsius ±1.0 Degrees Celsius Temperature deviation on PCB ±2.0 Degrees Celsius ±2.0 Degrees Celsius Data storage Process data and status storage(80 GB) Abnormal alarm Abnormal temp.(extra-high/extra -low temperature) Board dropped alarm Tower light:yellow-warming;green-normal;red-abnormal Max. Width of pcb 320mm 320mm Conveyor height 880±20mm 880±20mm Conveyor direction L-R/R-L L-R/R-L Conveyor speed range 0-1500mm 0-1500mm Pcb transmission agent Mesh Mesh Normal power 4.5KW 5.5KW Start-up power 18KW 24KW
Product Description:
Main product : reflow oven, smt reflow oven, reflow solder, reflow soldering,smt mounter,Smt Pick and Place Machine,Smt Placement Machine,Smt Mounting Machine, Pcb Machine,Smt Assembly,Smt Equipments
Futures:
A.The unique advanced long life heating system
1. The heating system adopt the Swedish nickel flipping pipe which with high efficiency and energy saving. The peak wave length of radiation power is 4UM with curved surface reflector to accelerate the rising temperature speed, improve the thermal efficiency. And the special forced-air circulation system makes PCB and the component heated uniform and eliminates the "shadow effect" completely.
2. Special high temperature resistant protection system (the United States of America's high density insulation rock wool in heat preservation system and special iron in furnace. It suit for lead free welding and the welding area with rosin flux recovery system to protect environment.
3. Using imported Taiwan SanYue long axis of high temperature fan motor.
4. Whole oven are porous aluminum transfer the hot air to guarantee the hot air evenly to the PCB. The whole top oven can open completely easy to clean oven inside.
B.Smooth and reliable transmission system
1.The transmission system use STK adjustable speed motor imported from Taiwan matched with the 1:150 turbine reducer can running smooth and to speed 0-1500mm/min.frequency stepless speed regulation.
2. Independent wheel structure and support and match with accompany stainless belt to make the running smooth and the speed precision is up to20mm/min.
3. Special stainless belt: durable and wear-resistant, not easy to deform by long time use.
C.The Electrical control system is stable and reliable.
1. It adopts imported thermostat control which owns fuzzy control and PID intelligent precision control system. It can fast response the changes in external heat and ensure more temperature balanced by PID intelligent operation and automatic control heat.
2. Using Fanda thermocouple imported from Taiwan by each temperature zone, it can fast and sensitive induct the changes in each temperature zone, transfer and control timely, compensate the temperature balance in each zone.
3. Special SSR solid state relay matched with dedicated radiator improve the heat efficiency greatly and prolong the service time effectively. No contact output and the fuzzy control function by thermostat, can monitoring the changes in the outside temperature and calorific value, controlling the heating device by the minimum pulse, ensuring the high precision of temperature control & the uniform temperature in internal and the length, direction, temperature distribution ,all of these meet IPC standard.
4. Power is abundant, heat up fast, it's only need 20 minutes from room temperature to constant temperature.
5. Failure diagnosis and sound and light alarm.
Delay shutdown protection function, uniform cooling after the shutdown: prevent component deformation.
