• Model NO.：GZR-1400
• Type：High-speed Stranding Machine
• Max Center Distance of Spindle (mm)：1450
• Max Working Torque N.M：250
• Winding Speed (Rpm)：0-200
• Outer Dia.(mm)：800
• Coil Height(mm)：1400
• Max Coil Weight(Kg)：1000kg
• Round Wire(mm)：0.3-3.5
• Flat Wire(mm)(Max)：4,15
• Automatic Alignment Function：Minimum Pitch of Wire 0.01mm
• Transport Package：Standard
• Specification：7000*3000*1400mm
• Trademark：Senerge
• Origin：Zhejiang
• HS Code：8479811
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. GZR-1400 Type High-speed Stranding Machine Max Center Distance of Spindle (mm) 1450 Max Working Torque N.M 250 Winding Speed (Rpm) 0-200 Outer Dia.(mm) 800 Coil Height(mm) 1400 Max Coil Weight(Kg) 1000kg Round Wire(mm) 0.3-3.5 Flat Wire(mm)(Max) 4,15 Automatic Alignment Function Minimum Pitch of Wire 0.01mm Transport Package Standard Specification 7000*3000*1400mm Trademark Senerge Origin Zhejiang HS Code 8479811 Production Capacity 30 Sets/Month

Product Description

GZR-1400 HV winding machine

1. Summary
GZR-1400 type automatic winding machine applies to winding coils for various types of small distribution transformer, current transformer and reactor etc.
It consists of winder, automatic wire pitch setter, layer insulation feeder, tension adjustable pay-off stand, pneumatic system, PLC control and servo system. Having the advantages of high automatic, complete functions, strong power etc. and ensures the axial and radial tightness of coil and it also can be used to manufacture square coil.

2. Main Specification
Center Height (mm)                           850
Max Center distance of spindle (mm)             1450
Spindle specification(mm)         50*90 or 40*40or 50*50or 60*60
Max working torque N.M                       250
Winding speed (rpm)                          0--200
Speed adjustment way               Stepless frequency control

Coil applicable
Outer Dia.(mm)                          ≤800
Coil height(mm)                         ≤1400
Max Coil weight(kg)                     1000kg
Machine power (kw)                        6
Max. set turns                           9999.9

Wire Specification
Round wire(mm)                         Φ0.3-Φ3.5
Flat wire(mm)(Max)                        4*15
Automatic alignment function        Minimum pitch of wire 0.01mm

Counting mode
5-digital display, can set total turns with 20 sub-turns, reverse counting available, power-off  memory .also can Pre-set 30 groups of winding data.

Power supply                          AC 380V 50HZ
Machine weight(kg)                      2500
Main machine dimension(L*W*H) (mm)    3100*1400*1400
Working space (L*W*H)mm              7000*3000*1400
