Stator Coil Winding and Coil Inserting Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Customized Service：Provided
- Transport Package：Wooden Case
- Specification：Middle Size
Base Info
- Model NO.：WIND-RXJ
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-RXJ Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Stator Coil Winding and Coil Inserting Machine
This machine is equipped with 4 working stations, two for winding, one for wedge cutting, one for coil insertion.It is suitable for stators with high slot filling rate.
(1) Specification
| Stator ID | 40~100mm |
| Stator OD | Max 160mm |
| Stack length | 20~100mm |
| Tooling stroke | Max 110mm |
| Suitable wire material | Copper/Aluminium wire |
| Slot number | 16~36slots |
| Power | 22KW |
| Weight | 3500KG |
| Dimension | 1250x1800x2350mm |
(2) Application
This type of machine is suitable for small type AC motor, induction motor stators.
(3) Feature
Four working station
Can do both coil winding and coil inserting
Manual loading and unloading
Can be customized accordingly
Parameter of different models can be edited, modified and displayed
Quick and easy readjustment for other types of stator
Copper wire and aluminium wire are both applicable
Easy for operation, No skilled operator required
