Odd / Even Slot Rotor Winding Solution Coil Winding Machine
Shanghai Wind Automation Equipment Co., Ltd.- Voltage：220V
- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
Base Info
- Model NO.：WIND-2B-TD
- Automatic：Automatic
- Transport Package：Wooden Case
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-2B-TD Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Odd / Even Slot Rotor Winding Solution Coil Winding Machine
This machine is of high automation and yield rate, which can reach 98%.
(1)Specification
| Wire range | 0.2~1.2mm |
| Armature OD | 20~90mm |
| Stack height | 10~130mm |
| Commutator OD | 8~60mm |
| Movement | Jog/auto |
| Slot No. | Odd/Even |
| Turn No. | 0~9999 |
| Flyer speed | 0~2000rpm |
| Power supply | AC 220V 50/60HZ |
| Air source | 5~7kg/cm3 |
| Power | 3.5KW |
| Weight | 830KG |
| Dimension | 1530x1280x1650mm |
(2)Feature
For riser type commutator
With medium and big wire diameter
Manual loading and unloading
Can work as a stand-alone machine or integrated into a production line
All winding parameter programmed on touch screen
This machine is suitable for slotted type armature with riser type commutator.
(4)Machine Operation
1)Put the armature on the tooling
2)Then press the start button.
3)Machine will wind the armature automatically
4)Unload wound armature
