Single Screw Extruder/Silicone Cable Machine/Electrical Machinery /Cable Machine
Dongguan Newtopp Electrical Machinery Co., Ltd.- Driven Type：Electric
- Condition：New
- Certification：CCC, PSE, UL, FDA, RoHS, ISO, CE
- Warranty：12 Months
- Screw：Single-Screw
- Transport Package：Standard Shipping Packing
Base Info
- Model NO.：XJ-115
- Specification：XJ115
- Trademark：Newtopp
- Origin：China
- HS Code：8477209000
- Production Capacity：60 Sets,Year
Description
Suitable for extrusion production of various high temperature silicone cables.Main power 10HP 20HP 30HP 50HP Extrusion capacity 30kg/H 60kg/H 150kg/H 250kg/H Screw diameter Φ45mm Φ65mm Φ90mm Φ115mm Screw L/D 14:1 14:1 14:1 14:1 Pay-off bobbin Φ300-400mm Φ400-630mm Φ1000-1250mm Φ1250-1600mm Inlet diameter Φ0.2-3.0mm Φ0.3-5.0mm Φ1.0-20mm Φ3.0-45mm Finished diameter Φ0.8-5.0mm Φ1.8-8.0mm Φ3.0-25mm Φ6.0-55mm Vulcanize length 12M 16M 24M 28M Heating power 6 Zones 32KW 6 Zones 32KW 8 Zones 42KW 10 Zones 54KW Capstan power 3KW 4KW 7.5KW 11KW Line speed 6-80M/min 6-80M/min 4-80M/min 4-80M/min Take-up bobbin Φ400-500mm Φ400-630mm Φ1250-1600mm Φ1250-1600mm
Main parts brand
1.Motor: Siemens
2.Frequency converter: Yaskawa
3.Bearing: NSK (Japan brand)
4.Electrical component: Siemens or Omron
5.PLC controller: Siemens
Our Service
Pre-Sales Service After-Sales Service
* Inquiry and consulting support. * Training how to install and how to use the machine
* Customized design support. * Engineers available to service machinery overseas.
* View our Factory.
About us
Company introduction
Dongguan NewTopp Electrical Machinery Co.,Ltd is a high-tech enterprise which professional in design and manufacture high-end wire and cable equipment,manily have the whole factory production line solution of Civil construction/power wire&cable,whole factory production line solution of Lan cable cat8/5E/6/6A/7,whole factory production line solution of HDMI,USB,SATA,RG59,6 etc. High frequency wire and cable,equipment include the copper bunching machine,teflon extrusion machine,insulation extrusion machine, chemical foaming extrusion machine,physical foaming extrusion machine,jacket sheath extrusion machine,planetary type cage twisting/stranding machine, numerical control type double layers/multi layers taping machine,cantilever type single twisting/stranding machine,Lan cable back-twist pair twisting/stranding machine etc. For more information please log in our official website http://dgnewtopp.en.made-in-china.com or feel free to contact us directly.
Our products
Products in client site
Certification and Patent
Contact us
Contact person: Mr. David hou
DongGuan Newtopp Electrical Machinery Co.,Ltd.
http://dgnewtopp.en.made-in-china.com
Add.:No.286, Huaide Road, Humen Town,Dongguan City, Guangdong Province.
