Horizontal Type Stator Coil Middle Forming Machine Winding Shaping Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Customized Service：Provided
- Transport Package：Wooden Case
- Specification：Middle Size
Base Info
- Model NO.：WIND-300-MF
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-300-MF Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Horizontal Type Stator Coil Middle Forming Machine Winding Shaping Machine
Adapting PLC system, horizontal structure and auto feeding device design, loading/unloading by movable crane, this machine is suitable for big power or big size motor winding forming. It adapts the schematic of inner expansion, outside wrapping and over-hang impacting forming. The circulate impacting times and retaining time is settable in the system.
(1) Specification
| Stack length | 70~250mm |
| Stator ID | 110~210mm |
| Stator OD | Max 300mm |
| Oil pump displacement | 40L |
| Power supply | 380V 50/60HZ |
| Weight | 2300KG |
| Dimension | 3716x1238x2110mm |
(2) Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly
Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required
(3) Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor, generator motor and pump motor.
