Winding Forming Machine Final Forming Machine for Stator Coils
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Customized Service：Provided
- Transport Package：Wooden Case
- Specification：Middle Size
Base Info
- Model NO.：WIND-160-FF
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-160-FF Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Winding Forming Machine Final Forming Machine for Stator Coils
This machine has advantages of mature and advanced technology, reliable quality, easy operation and maintenance. The forming for external of coil adopts sliding block folding to restrict the diameter, while the inner block to make the internal coil diameter reach requirement.
(1) Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly
Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required
(2) Specification
| Stack length | 16~100mm |
| Stator ID | 50~100mm |
| Stator OD | Max 160mm |
| Oil pump displacement | 20F |
| Power supply | 380V 50/60HZ |
| Weight | 700KG |
| Dimension | 650x900x2300mm |
(3) Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor, generator motor and pump motor.
