Stator Winding Forming Machine Coil Shaping Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty:12 Months
- Color:Customized
- After-Sales Service:Engineers Avaiable to Service Overseas
- Customized Service:Provided
- Transport Package:Wooden Case
- Specification:Middle Size
Base Info
- Model NO.:WIND-160-MF
- Trademark:Wind Automation
- Origin:China
- HS Code:8479811000
- Production Capacity:100 Sets,Year
Description
Basic Info.
Model NO. WIND-160-MF Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Stator Winding Forming Machine Coil Shaping Machine(1) Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly
Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required
(2) Specification
Stack length | 16~100mm |
Stator ID | 30~100mm |
Stator OD | Max 160mm |
Oil pump displacement | 20F |
Power supply | 380V 50HZ |
Weight | 1000KG |
Dimension | 1200x750x2500mm |
(3) Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor, generator motor and pump motor.
