Stator Automatic Final Coil Shaping Winding Forming Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Customized Service：Provided
- Transport Package：Wooden Case
- Specification：Middle Size
Base Info
- Model NO.：WIND-160-FF
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-160-FF Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Stator Automatic Final Coil Shaping Winding Forming Machine
Final forming machine is consisted of machine framework, oil hydraulic power system, control system, and forming tooling system. Powered by hydraulic system, machine drives the forming tooling system, so as to control the expansion and shrink of expansion blade and forming blade to complete the stator coil forming.
(1) Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly
Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required
(2) Specification
| Item | Data |
| Size | (L)950×(W)1550×(H)2400mm |
| Tooling included weight | Around 800KG |
| Power supply | 380V/50Hz three phase four wire power |
| Working pitch time | ≤13S/PC |
| ID | Φ30~Φ120mm |
| OD | Φ50~Φ160mm |
| Stack height | 15~300mm |
(3) Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor, generator motor and pump motor.
