Air Conditioner Motor Stator Winding Shaping Coil Forming Machine

Shanghai Wind Automation Equipment Co., Ltd.
  • Warranty:12 Months
  • Color:Customized
  • After-Sales Service:Engineers Avaiable to Service Overseas
  • Customized Service:Provided
  • Transport Package:Wooden Case
  • Specification:Middle Size

Base Info

  • Model NO.:WIND-160-FF
  • Trademark:Wind Automation
  • Origin:China
  • HS Code:8479811000
  • Production Capacity:100 Sets,Year

Description

Basic Info.

Model NO. WIND-160-FF Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/Year

Product Description

Air Conditioner Motor Stator Winding Shaping Coil Forming MachineAir Conditioner Motor Stator Winding Shaping Coil Forming Machine

This machine is used to do coil forming after lacing process. The head coil forming will be processed after the forming of internal and external of coil completed.

(1) Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly

Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required


(2) Specification

ItemData
Size(L)950×(W)1550×(H)2400mm
Tooling included weightAround 800KG
Power supply380V/50Hz three phase four wire power
Working pitch time≤13S/PC
IDΦ30~Φ120mm
ODΦ50~Φ160mm
Stack height15~300mm


(3) Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor,  generator motor and pump motor.
