• Model NO.：N300
• Product Name：3 Zones SMT Full Automatic Tht Assembly Line Wave
• Lead Time：20-50days
• Usage：SMT Assembly Line
• Quality：100% Tested
• Weight：1000kg
• Transport Package：Vacuum Packing
• Specification：2800(L)*1250(W)*1560(H) mm
• Trademark：Morel
• Origin：China
• Production Capacity：50set,Month

Basic Info.

Model NO. N300 Product Name 3 Zones SMT Full Automatic Tht Assembly Line Wave Lead Time 20-50days Usage SMT Assembly Line Quality 100% Tested Weight 1000kg Transport Package Vacuum Packing Specification 2800(L)*1250(W)*1560(H) mm Trademark Morel Origin China Production Capacity 50set/Month

Product Description

Product description:

SMT Full Automatic THT Assembly line Wave Soldering - N300



Number of Pre-heaters	3
Pre-heater Passage	1450mm
Body size	2800(L)*1250(W)*1560(H)
Outside dimension	3600(L)*1250(W)*1560(H)
Weight	1000KG
Total/steady consumption	19KW/5-7KW
Air supply	0.5MPa
Preheater style	Hot air

Preheater consumption	220V 6KW
Control  method	PC +PLC/press keys/Touch screen
Range of temp. set-point	Room temperature-300ºC
Preheating time	About 10-15mins for setting 150ºC
Solder Application	Lead-free / Sn-Pb
Solder pot capacity	280KG
Solder pot temperature	300ºC

Solder pot consumption	380V 9KW
Solder temp. control method	PID&SSR
Wave motor power	1KW 220V
Solder melting	About 120mins for setting 250ºC
PCB  width	50-300mm
Conveyor speed	0-1800mm/min
Conveyor direction	L→R (R→L optional)
Conveyor inclination	4-7 º
Flux pressure/capacity	3-5 bar/5.2L
