• Model NO.：N200
• Product Name：2 Zones SMT Full Automatic Tht Assembly Line Wave
• Lead Time：20-50days
• Usage：SMT Assembly Line
• Quality：100% Tested
• Weight：700kg
• Transport Package：Vacuum Packing
• Specification：1800(L)*1200(W)*1600(H)mm
• Trademark：Morel
• Origin：China
• Production Capacity：50set,Month

Basic Info.

Model NO. N200 Product Name 2 Zones SMT Full Automatic Tht Assembly Line Wave Lead Time 20-50days Usage SMT Assembly Line Quality 100% Tested Weight 700kg Transport Package Vacuum Packing Specification 1800(L)*1200(W)*1600(H)mm Trademark Morel Origin China Production Capacity 50set/Month

Product Description

Product description:

SMT Full Automatic THT Assembly line Wave Soldering - N200



Number of Pre-heaters	2
Pre-heater passage	600mm
Body size	1800(L)*1200(W)*1600(H)
Outside dimension	2600(L)*1200(W)*1600(H)
Weight	700KG
Total/steady consumption	11KW/4-6KW
Air supply	0.5MPa
Preheating style	Hot air
Preheater consumption	220V 5KW

Control  method	Press key +PLC (Option: touch screen, PC)
Range of temp. set-point	Room temperature-300ºC
Preheating time	About 10-15mins for setting 150ºC
Solder application	Lead-free / Sn-Pb
Solder pot capacity	220KG
Solder pot temperature	300ºC
Solder pot consumption	380V 6KW

Solder temp. control method	PID&SSR
Wave motor power	500W 220V
Solder melting	About 120mins for setting 250ºC
PCB  width	50-250mm
Conveyor  speed	0-1800mm/min
Conveyor  direction	L→R (R→L optional)
Conveyor Inclination	4-7 º
Flux pressure	3-5 bar
Flux capacity	3.2L
