Semicircle Core Toroidal Coil Winding Machine

Wisdom Import & Export (Shanghai) Co., Ltd.
  • Voltage：220V
  • Head Type：Slider Type
  • Coil O.D.：8-60mm
  • Min.Fin. I.D.：5mm
  • Max. Height：25mm
  • Wire Size：0.05~0.25mm

Base Info

  • Model NO.：TT-FC01X
  • 0.05~0.25mm：98mm
  • Speed：1500rpm
  • Winding Motor：370W AC Motor, Variable Frequency Drive
  • Spread Motor：Stepping Motor
  • Memory Capacity：999 Steps
  • Precision：High Precision
  • Demoulding：Pull Core
  • Heating System：No
  • Function：High
  • Mould Life：>1, 000, 000 Shots
  • Automatic：Semi-Automatic
  • Certification：CE, ISO
  • Transport Package：Plywood Box, According Custormer′s Requirement
  • Specification：high quality
  • Trademark：WISDOM
  • Origin：China
  • HS Code：8479811000
  • Production Capacity：500 Sets Per Month

Description

Basic Info.

Model NO. TT-FC01X 0.05~0.25mm 98mm Speed 1500rpm Winding Motor 370W AC Motor, Variable Frequency Drive Spread Motor Stepping Motor Memory Capacity 999 Steps Precision High Precision Demoulding Pull Core Heating System No Function High Mould Life >1, 000, 000 Shots Automatic Semi-Automatic Certification CE, ISO Transport Package Plywood Box, According Custormer′s Requirement Specification high quality Trademark WISDOM Origin China HS Code 8479811000 Production Capacity 500 Sets Per Month

Product Description


semicircle core toroidal coil winding machine

digital automatic slider toroid winding machine adopts CNC toroid controller, it is slider type winding shuttle.It's an accurately and reliability digital toroid-winding machine. is used for toroidal inductor, toroidal transformer, toroidal current transformer, toroidal current sensor, toroidal coil, toroid chock coil, power inductors, power magnetics,UPS inductor,  converter inductors, watter metter sensors, toroid current transformer of electronic watter-hour meter, etc.
SPEED: 1500rpm
WINDING MOTOR: 370W AC motor, variable frequency drive
SPREAD MOTOR: Stepping Motor
MEMORY CAPACITY: 999 STEPS

Semicircle Core Toroidal Coil Winding Machine

 Collocate the Belt type winding head or Slider type winding head to reduce the cost
 Hi-tech shuttle for highest efficiency.
 Separate speed controls for loading and winding.
 Accurately count length of loading by Photoelectric sensor switch.
 Accurately count turns of winding by OMRON  sensor
 Programmable winding direction, winding returns range (Turns or Angle) and segment winding angle
 Accurately wire spacing by programmable controller
 Memory capacity accommodates 999 sequences of parameters with off-power memory retention for more than ten years.
