Shaded Motor Power Tool Motor Stator Automatic Coil Winding Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Customized Service：Provided
- Transport Package：Wooden Case
- Specification：Middle Size
Base Info
- Model NO.：WIND-SW-2
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-SW-2 Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Shaded Motor Power Tool Motor Stator Automatic Coil Winding Machine
This machine is specially designed for two-poles series motor, shaded pole motor, power tool motor stator to do coil winding. It is controlled by Mitsubishi PLC. All parameter can be programmed on touch screen. Two working station do synchronous winding. (1) Specification
| Power supply | AC 220V |
| Air pressure | 0.5~0.7MPa |
| Total power | 2KW |
| Winding speed | 0~300r/min |
| Wire range | 0.11~1.0mm |
| Stator ID | Min 25mm |
| Stack length | Max 50mm |
| Slot width | Min 2.5mm |
(2)Application
suitable for two poles stators.
(3)FeaturesNo skilled operator requiredThis machine can be customized accordinglyRigid design frameFully automatic working cycle after loading of the statorQuick change-over of toolingPLC control, fault display
