Generator Stator Coil Winding Shaping Machine
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- After-Sales Service：Engineers Avaiable to Service Overseas
- Customized Service：Provided
- Transport Package：Wooden Case
- Specification：Middle Size
Base Info
- Model NO.：WIND-CX-C
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-CX-C Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Generator Stator Coil Winding Shaping Machine
This machine adopts hydraulic drive to do coil forming process. Squash in radial at the same time from 4 directions after internal expansion. It has a wide application and easy to operate. (1) Specifications
| Up and down installation travel | 200~260mm |
| Up and down work travel | 20~35mm |
| Horizontally material feeding travel | 200mm |
| Horizontally radial shaping travel | 20~35mm |
| Power | 5.5 KW |
| Power supply | AC 380 |
| Air pressure | 0.5~0.7MPa |
(2) Application
The stator coil forming machine is suitable for alternator, generator, AC motor and other industry motors.
(3) Features
Mitsubishi PLC program control and LCD display interface
Easy operation and tooling change
Suitable for multi-models production
Wide compatibility property
All the process will be done by machine automatically except for loading and unloading
